PreSonus StudioLive AR8C 8-Channel Hybrid Performance and Recording Mixer

Building upon the success of the original AR8-USB, the PreSonus StudioLive AR8C 8-Channel Hybrid Performance and Recording Mixer is an 8-channel hybrid performance and recording mixer well suited for a variety of applications including mixing and recording live shows, studio productions, band rehearsals, podcasts, and more. Updates to the AR8c include a USB Type-C connection, Bluetooth 5.0, and a redesigned mixer panel and layout. The mixer is packed with analog connections and digital tools that are powerful, yet easy to learn and use. The mixer features XMAX Class-A preamps and 3-band EQ.

The StudioLive AR8c offers recording with or without a computer. Multitrack record and fly in backing tracks with its 24-bit / 96 kHz, USB 2.0 audio interface or record and playback a stereo mix with the integrated SD digital recorder. Additionally, the mixer features a Super Channel, which allows you to connect four stereo analog and digital sources at once, enabling the mixer to be used with high-tech devices including smartphones and tablets for wireless Bluetooth streaming. The StudioLive AR8c ships with a power cord, USB cable, Studio One 3 Artist production software, and Capture recording software.

PreSonus StudioLive AR8C 8-Channel Hybrid Performance and Recording Mixer - Channels and Buses

• 8-channel mixer
• 2 mono and 2 stereo channels, each with:
  • Level knob
  • Pan
  • Mute
  • PFL solo
• 1 stereo Super Channel (Ch. 7/8)
• 1 aux buses with AFL solo
• 1 stereo effects bus
• 1 stereo effects return with:
  • Master level control knob
  • Dedicated aux send
  • Effects bypass footswitch jack

PreSonus StudioLive AR8C 8-Channel Hybrid Performance and Recording Mixer - Inputs and Outputs

• 2 instrument inputs
• 8 balanced line inputs
• 4 balanced mic inputs with:
  • Class-A microphone preamp
  • Global 48V phantom power
• Stereo Super Channel with:
  • Stereo RCA inputs
  • 1/8-inch stereo input
  • Switchable SD/USB stereo playback
  • Bluetooth 5.0 input
• L/R XLR main outputs
• 1 balanced TRS aux outputs
• 1 balanced TRS effects output
• L/R Control Room outputs with level control
• Headphone output with level control

PreSonus StudioLive AR8C 8-Channel Hybrid Performance and Recording Mixer - Signal Processing

• High-pass filter on channels 1 and 2
• +10 dB button on 3/4 and 5/6
• 3-band semi-parametric EQ (Channels 1-6)
• Stereo effects processor with 16 presets

PreSonus StudioLive AR8C 8-Channel Hybrid Performance and Recording Mixer - Recording Options

• 8x4 24-bit / 96 kHz, USB 2.0 (over USB Type-C connection) audio recording interface
  • Record every channel plus the Main Mix
• 2x2 SD recorder
  • Record main mix
  • Supports SD and SDHC formats up to 32 GB

PreSonus StudioLive AR8C 8-Channel Hybrid Performance and Recording Mixer - Integrated Software

• Capture recording software
• Includes Studio Magic Plug-in Suite with Maag Audio EQ 2, SPL Attacker, Arturia instruments, and more
• Includes Studio One 3 Artist software (DAW)
