Samson Concert 88X Guitar 16-Channel True Diversity UHF Wireless System Band D SWC88XBGT-D

Samson Concert 88X Guitar 16-Channel True Diversity UHF Wireless System Band D SWC88XBGT-D

The Concert 88X offers musicians straightforward operation and quality performance. It features a bodypack transmitter with a mini XLR to 1/4" guitar cable along with a tabletop true-diversity receiver with XLR and 1/4" outputs and a rackmount kit. With 100 available frequencies, simple syncing via IR, and one-touch automatic frequency scanning, you can quickly get started and find a strong channel. With two AA batteries the bodypack transmitter will be powered for up to 8 hours. It is easy to set up and operates reliable. By operating from 542 to 566 MHz in the UHF spectrum, it avoids interference from Bluetooth and Wi-Fi signals. The tabletop receiver includes a rackmount kit that can be installed in an equipment rack or road case. Its balanced XLR and unbalanced 1/4" outputs enable proper hookup to mixers, audio recorders, and PA systems.

Samson Concert 88X Guitar 16-Channel True Diversity UHF Wireless System Band D SWC88XBGT-D Features:

• For Guitar, Bass, Instrument
• Bodypack Transmitter & Instrument Cable
• CR88x Tabletop Receiver
• One-Touch Automatic Frequency Scan
• True Diversity, Dual-Antenna Design
• Balanced XLR and Unbalanced 1/4" Outputs
• 8-Hour Run Time via AA Batteries
• Up to 8 Channels per Band / 300' Range

Specifications:

System

• Wireless Technology: Analog UHF
• Number of RF Channel Frequencies: 100
• Included Transmitters: 1 x Bodypack with Cable
• Diversity: True Diversity
• RF Frequency Band: D: 542 to 566 MHz
• RF Bandwidth: Up to 25 MHz
• RF Channel Scanning: Auto-Scan
• Max Operating Range: 300' / 91.4 m (Line of Sight)
• Max Transmitters per Band: 8
• Dynamic Range: >100 dBA
• Pilot Tone: 35 kHz
• SNR: >90 dBA
• THD: <1 %

Receiver

• Receiver Type: Tabletop
• Mounting Options: Rackmount, Tabletop (with Included Hardware)
• Rackmount Size: 1 RU (1/2 Rack)
• Antenna: 2 x 1/4 Wave External, Fixed (Front-Mount)
• Number of Audio Channels: 1
• Audio I/O:
  • 1 x XLR 3-Pin Male Balanced Output
  • 1 x 1/4" TS Female Unbalanced Output
• Audio Output Level
  • XLR Output:
    • +9 dBu
  • 1/4" Output:
    • +14 dBu
• Frequency Response: 50 Hz to 15 kHz (Dependent on Mic)
• Impedance
  • XLR Output:
    • 240 Ohms
  • 1/4" Output:
    • 810 Ohms
• Approximate RF Sensitivity: -100 dBm
• Power Requirements: AC/DC Power Adapter
• Display & Indicators
  • 1 x LCD (Channel)
  • 1 x LED (Data Transmission)
  • 1 x LED (Clip)
  • 1 x LED (Sync)
• Operating Temperature: 14 to 140?øF / -10 to 60?øC
• Dimensions: 8.3 x 1.7 x 4.9" / 21 x 4.4 x 12.5 cm
• Weight: 14.1 oz / 400 g

Transmitter

• Transmitter Type: Bodypack with Cable
• RF Output Power: 10 mW (EIRP)
• Audio I/O: 1 x TA3/Mini XLR 3-Pin Male Input
• Included Cable Connector: 1/4" TS
• Pad: None
• Muting: Off/On Switch
• Gain Range: 38 dB
• Signal Processing: None
• Sync Method: IR
• Antenna: 1 x Flexible Whip, Fixed
• Power Requirements: Battery
• Battery Type: 2 x AA (Not Included)
• Approx. Battery Life: 8 Hours
• USB/Lightning Connectivity: None
• Display & Indicators: 1 x LED (Battery Status, Mute, Power)
• Housing: Plastic
• Dimensions: 2.4 x 3.8 x 0.7" / 62 x 96 x 18.5 mm
• Weight: 3.3 oz / 93 g
